Product details
Features & specifications
Bambu Lab H2D Laser Full Combo combines the dual-nozzle H2D Laser Edition 3D printer with the AMS 2 Pro, a laser module, and a cutting module, so one machine can print, engrave, cut, and draw. Choose the 10W or 40W laser option when you order.
Highlights
- Print, laser, and cut. The laser module engraves and cuts materials such as wood, leather, and dark acrylic, while the cutting module handles paper, vinyl, and pen drawing.
- Laser safety features. Laser protective windows, a built-in air pump, flame and temperature detection, a safety key, and an emergency stop button.
- Dual-nozzle printing. Two nozzles change filaments with less time and material waste than a single-nozzle printer, which suits multi-material prints and supports.
- Expandable filament system. Up to 4 AMS 2 Pro and 8 AMS HT units can connect for up to 24 slots, and an external spool on the second nozzle brings that to 25 filament configurations. A 4-in-1 PTFE Adapter (FAZ013-N) is needed to connect more than two AMS units.
- Motion accuracy and monitoring. 5μm resolution optical motion calibration, a closed-loop servo extruder, and AI print monitoring help catch problems early.
Specifications
| Build volume | Single nozzle: 325 x 320 x 325mm; dual nozzle: 300 x 320 x 320mm |
| Max nozzle temperature | 350°C |
| Max heatbed temperature | 120°C |
| Max chamber temperature | 65°C (active heating) |
| Max toolhead speed | 1,000mm/s |
| Max acceleration | 20,000mm/s² |
| Laser engraving speed | 10W: 400mm/s; 40W: 1,000mm/s |
| Max laser cutting thickness | 10W: 5mm; 40W: 15mm (basswood plywood) |
| Engraving area | 10W: 310 x 270mm; 40W: 310 x 250mm |
| Blade cutting area | 300 x 285mm, up to 0.5mm thick |
| Drawing area | 300 x 255mm |
| Cameras | 1920 x 1080 live view, nozzle, and toolhead cameras; 3264 x 2448 BirdsEye camera |
| Voltage | 100-120 VAC, 50/60 Hz |
| Physical dimensions | 492 x 514 x 626mm |
What's Included
| Item | 40W | 10W |
|---|---|---|
| Bambu Lab H2D Laser Edition | ✓ | ✓ |
| AMS 2 Pro | ✓ | ✓ |
| 40W laser module | ✓ | - |
| 10W laser module | - | ✓ |
| Cutting module with pen holder | ✓ | ✓ |
| Laser platform | ✓ | ✓ |
| Cutting platform | ✓ | ✓ |
| Textured PEI build plate | ✓ | ✓ |
| Spool holder | ✓ | ✓ |
| Safety key | ✓ | ✓ |
| Ventilation pipe | ✓ | ✓ |
| Emergency stop button | ✓ | ✓ |
| Laser and cutting materials | ✓ | ✓ |
| Accessory box | ✓ | ✓ |
Buying from fbrc8
- Filament. This printer uses 1.75mm filament and works with materials including PLA, PETG, TPU, ABS, ASA, PA6-GF, PC, PPA-CF, and PPS-CF.
- Spare parts and consumables. We carry spare parts for this printer, as well as MakerSupply consumables for cutting and engraving.
- Shipping. FedEx Ground/Home Delivery rates apply for this product if shipping. If you prefer to ship via FedEx Freight, please email Sales@fbrc8.com for a quote.
